RAPID LF3015LN
Model: RAPID LF3015LN
Machine Size: 4450*4197*1860mm (175x165x73inches)
Working Area: 3000*1500mm (118x59inches)
Usage/Application: Industrial
Laser Power: 1500W, 2000W, 3000W
Machine Type: Fiber Laser Metal Cutting Machine
Cutting Material: Ms(CS), SS, Aluminum, Copper, Brass, GI
Working voltage: Three Phase AC220/380V/50HZ/60Hz working voltage
Power Source: MAX, RAYCUS
Applications include: Sign making, Sheet Metal, fabrication, Industrial etc
This product has been added to 150 people'scarts.
- Pick up at a edgeprint.ca collection point is possible
- Shipping
- 24 x 7 Customer Support
Description
The RAPID LF3015LN Fiber Laser Metal Cutting Machine is a professional industrial solution designed for high-precision and efficient metal cutting applications. With a 3000 × 1500mm working area and laser power options of 1500W, 2000W, and 3000W, it is suitable for a wide range of fabrication and manufacturing requirements.
Powered by reliable components including Japanese Yaskawa motors, French motor reducers, and Taiwan APEX racks, the RAPID LF3015LN is engineered for accuracy, stability, and consistent performance. Its machine tool precision can reach approximately 0.02mm, while cutting acceleration of up to 0.8G supports efficient production.
This fiber laser metal cutting machine can process materials such as mild steel (carbon steel), stainless steel, aluminum, copper, brass, and galvanized iron (GI). With an optional pipe-cutting feature, it can also support various metal plate and pipe processing applications.
The RAPID LF3015LN is ideal for sign making, sheet metal fabrication, industrial manufacturing, kitchenware, storage cabinets, metal components, and general fabrication work. With a robust industrial design and long working life, it offers a dependable combination of precision, versatility, productivity, and durability for modern metal-processing businesses.
| Model | RAPID LF3015LN |
| Laser Source | Laser Source (Raycus/Max) |
| Laser Power (Watt) | 1500W (1.5KW), 2000W (2KW), 3000W (3KW) |
| Working Area | 3000 × 1500mm (118 × 59 inch) |
| Maximum Speed | 80m/min |
| Z Axis Travel | 80mm (3.24 inch) |
| Working Platform Load | 600 kgs |
| Total Power for 1500W | Single Phase 11.2KW (51A), Three Phase 11.2KW (17A) |
| Total Power for 2000W | Three Phase 13.2KW (20A) |
| Total Power for 3000W | Three Phase 15.2KW (24A) |
| Cooling System | Industrial S&G Water Chiller |
| Electronic Components | France – Schneider |
| Gear Reducer | Japan Shimpo |
| Laser Head | Raytool |
| Guide Rail / Linear | Taiwan SHAC / Japan THK |
| Voltage | 380V 50Hz/60Hz/60A (±10%) |
| Working Environment | Temperature: 20–30℃ Humidity: 45–65% |
| Machine Size & Weight | 4450 × 4197 × 1860mm (175 × 165 × 73 inch), 1800 kgs (2204 lbs) |
| Packing Size (LWH) & Weight | 4600 × 4250 × 1900mm (181 × 167 × 174 inch), 2200 kgs (2866 lbs) |
| Material | 1500W | 2000W | 3000W |
|---|---|---|---|
| Stainless Steel | 1 to 8mm | 1 to 10mm | 1 to 12mm |
| Aluminum | 2 to 6mm | 1 to 8mm | 1 to 10mm |
| Brass | 1 to 5mm | 1 to 8mm | 1 to 10mm |
| Carbon Steel | 0.8 to 16mm | 1 to 20mm | 1 to 24mm |
| Copper | 1 to 3mm | 1 to 4mm | 1 to 6mm |
